JS-PCF 内螺纹直通 - 产品规格
除FKM氟橡胶外均为316材质，含卡簧。
| # | MODEL | Tube[mm] | R[mm] | M[mm] | L1[mm] | L2[mm] | H[mm] | A[mm] | D[mm] |
|---|---|---|---|---|---|---|---|---|---|
| 1 | JS6-PCF16-03 | 16 | Rc3/8 | 23.4 | 36.5 | 13 | 24 | 26.6 | 24 |
| 2 | JS6-PCF6-01 | 6 | Rc1/8 | 15.2 | 25 | 8 | 12 | 13.3 | 12 |
| 3 | JS6-PCF6-M5 | 6 | M5 | 15.2 | 21.4 | 5 | 12 | 13.3 | 12 |
| 4 | JS6-PCF4-M5 | 4 | M5 | 14.2 | 21.5 | 5 | 10 | 11.1 | 10 |
| 5 | JS6-PCF12-04 | 12 | Rc1/2 | 21 | 35.3 | 13 | 24 | 26.6 | 20 |
| 6 | JS6-PCF12-03 | 12 | Rc3/8 | 21 | 33.8 | 11 | 21 | 23.3 | 20 |
| 7 | JS6-PCF12-02 | 12 | Rc1/4 | 21 | 33.4 | 10 | 21 | 23.3 | 20 |
| 8 | JS6-PCF10-04 | 10 | Rc1/2 | 18.5 | 32.5 | 13 | 24 | 26.6 | 17 |
| 9 | JS6-PCF10-03 | 10 | Rc3/8 | 18.5 | 31.2 | 11 | 21 | 21.1 | 17 |
| 10 | JS6-PCF10-02 | 10 | Rc1/4 | 18.5 | 29.8 | 10 | 17 | 18.8 | 17 |
| 11 | JS6-PCF10-01 | 10 | Rc1/8 | 18.5 | 28.8 | 8 | 19 | 18.8 | 17 |
| 12 | JS6-PCF8-04 | 8 | Rc1/2 | 16.8 | 30.6 | 13 | 24 | 26.6 | 14 |
| 13 | JS6-PCF8-03 | 8 | Rc3/8 | 16.8 | 30.5 | 11 | 21 | 21.1 | 14 |
| 14 | JS6-PCF8-02 | 8 | Rc1/4 | 16.8 | 28.4 | 10 | 17 | 18.8 | 14 |
| 15 | JS6-PCF8-01 | 8 | Rc1/8 | 16.8 | 27.1 | 8 | 14 | 15.5 | 14 |
| 16 | JS6-PCF6-04 | 6 | Rc1/2 | 15.2 | 30.1 | 13 | 24 | 26.6 | 12 |
| 17 | JS6-PCF6-03 | 6 | Rc3/8 | 15.2 | 28.8 | 11 | 19 | 21.1 | 12 |
| 18 | JS6-PCF6-02 | 6 | Rc1/4 | 15.2 | 26.4 | 10 | 17 | 18.8 | 12 |
| 19 | JS6-PCF4-02 | 4 | Rc1/4 | 14.2 | 26.6 | 10 | 17 | 18.8 | 10 |
| 20 | JS6-PCF4-01 | 4 | Rc1/8 | 14.2 | 23.5 | 8 | 12 | 13.3 | 10 |
