JS-POC 圆螺纹直通 - 产品规格
除FKM氟橡胶外均为316材质，含卡簧。
| # | MODEL | Tube[mm] | R[mm] | M[mm] | L1[mm] | L2[mm] | H[mm] | D[mm] |
|---|---|---|---|---|---|---|---|---|
| 1 | JS6-POC10-04 | 10 | R1/2 | 18.5 | 24.6 | 12.5 | 8 | 21 |
| 2 | JS6-POC16-04 | 16 | R1/2 | 23.4 | 32.8 | 12.5 | 12 | 24 |
| 3 | JS6-POC16-03 | 16 | R3/8 | 23.4 | 35.8 | 10.5 | 12 | 24 |
| 4 | JS6-POC6-01 | 6 | R1/8 | 15.2 | 21.8 | 7.5 | 4 | 12.5 |
| 5 | JS6-POC6-M5 | 6 | M5 | 15.2 | 22.4 | 4 | 2 | 12.5 |
| 6 | JS6-POC12-04 | 12 | R1/2 | 21 | 30.7 | 12.5 | 10 | 21 |
| 7 | JS6-POC12-03 | 12 | R3/8 | 21 | 28.8 | 10.5 | 8 | 20 |
| 8 | JS6-POC12-02 | 12 | R1/4 | 21 | 31.8 | 9.5 | 6 | 20 |
| 9 | JS6-POC12-01 | 12 | R1/8 | 21 | 31.2 | 7.5 | 4 | 20 |
| 10 | JS6-POC10-03 | 10 | R3/8 | 18.5 | 26.7 | 10.5 | 8 | 17 |
| 11 | JS6-POC10-02 | 10 | R1/4 | 18.5 | 29.7 | 9.5 | 6 | 17 |
| 12 | JS6-POC10-01 | 10 | R1/8 | 18.5 | 27.7 | 7.5 | 4 | 17 |
| 13 | JS6-POC8-04 | 8 | R1/2 | 16.8 | 24 | 12.5 | 6 | 21 |
| 14 | JS6-POC8-03 | 8 | R3/8 | 16.8 | 22 | 10.5 | 6 | 17 |
| 15 | JS6-POC8-02 | 8 | R1/4 | 16.8 | 24.5 | 9.5 | 6 | 14 |
| 16 | JS6-POC8-01 | 8 | R1/8 | 16.8 | 26 | 7.5 | 4 | 14 |
| 17 | JS6-POC6-04 | 6 | R1/2 | 15.2 | 23.2 | 12.5 | 4 | 21 |
| 18 | JS6-POC6-03 | 6 | R3/8 | 15.2 | 21.2 | 10.5 | 4 | 17 |
| 19 | JS6-POC6-02 | 6 | R1/4 | 15.2 | 20.2 | 9.5 | 4 | 14 |
| 20 | JS6-POC4-M5 | 4 | M5 | 14.2 | 21 | 4 | 2 | 10 |
| 21 | JS6-POC4-02 | 4 | R1/4 | 14.2 | 20.2 | 9.5 | 3 | 14 |
| 22 | JS6-POC4-01 | 4 | R1/8 | 14.2 | 21 | 7.5 | 3 | 10 |
