产品详情

除FKM氟橡胶外均为316材质，含卡簧。

#	MODEL	Tube[mm]	R[mm]	M[mm]	D[mm]	L1[mm]	L2[mm]	H[mm]	A[mm]
1	JS6-PC6-M5	6	M5	15.2	11.5	21.1	4	12	13.3
2	JS6-PC4-M5	4	M5	14.2	9.5	20.5	4	10	11.1
3	JS6-PC16-04	16	R1/2	23.4	23.5	31.6	12.5	24	26.6
4	JS6-PC16-03	16	R3/8	23.4	23.5	34.6	10.5	24	26.6
5	JS6-PC12-04	12	R1/2	21	19.5	30.7	12.5	21	23.3
6	JS6-PC12-03	12	R3/8	21	19.5	28.4	10.5	21	23.3
7	JS6-PC12-02	12	R1/4	21	19.5	31.5	9.5	21	23.3
8	JS6-PC12-01	12	R1/8	21	19.5	29.5	7.5	21	23.3
9	JS6-PC10-04	10	R1/2	18.5	16.5	24.7	12.5	21	23.3
10	JS6-PC10-03	10	R3/8	18.5	16.5	26	10.5	17	18.8
11	JS6-PC10-02	10	R1/4	18.5	16.5	29	9.5	17	18.8
12	JS6-PC10-01	10	R1/8	18.5	16.5	27	7.5	17	18.8
13	JS6-PC8-04	8	R1/2	16.8	13.5	24	12.5	21	23.3
14	JS6-PC8-03	8	R3/8	16.8	13.5	22	10.5	17	18.8
15	JS6-PC8-02	8	R1/4	16.8	13.5	23.5	9.5	14	15.5
16	JS6-PC8-01	8	R1/8	16.8	13.5	25	7.5	14	15.5
17	JS6-PC6-04	6	R1/2	15.2	11.5	23.2	12.5	21	23.3
18	JS6-PC6-03	6	R3/8	15.2	11.5	21.2	10.5	17	18.8
19	JS6-PC6-02	6	R1/4	15.2	11.5	20.2	9.5	14	15.5
20	JS6-PC6-01	6	R1/8	15.2	11.5	20.1	7.5	12	13.3
21	JS6-PC4-02	4	R1/4	14.2	9.5	20.2	9.5	14	15.5
22	JS6-PC4-01	4	R1/8	14.2	9.5	20	7.5	10	11.1
