JS-PB T型正螺纹三通 - 产品规格
除FKM氟橡胶外均为316材质，含卡簧。
| # | MODEL | Tube[mm] | L1[mm] | L2[mm] | L3[mm] | D2[mm] | CH1[mm] | CH2[mm] |
|---|---|---|---|---|---|---|---|---|
| 1 | JS6-PB12-04 | 12 | 67 | 38 | 12.5 | 20.5 | 15.5 | 21 |
| 2 | JS6-PB12-03 | 12 | 67 | 36 | 10.5 | 20.5 | 15.5 | 17 |
| 3 | JS6-PB12-02 | 12 | 67 | 35 | 9.5 | 20.5 | 15.5 | 14 |
| 4 | JS6-PB10-04 | 10 | 58.8 | 35.5 | 12.5 | 17.5 | 13.2 | 21 |
| 5 | JS6-PB10-03 | 10 | 58.8 | 33.5 | 10.5 | 17.5 | 13.2 | 17 |
| 6 | JS6-PB10-02 | 10 | 58.8 | 32.5 | 9.5 | 17.5 | 13.2 | 14 |
| 7 | JS6-PB10-01 | 10 | 58.8 | 30.5 | 7.5 | 17.5 | 13.2 | 12 |
| 8 | JS6-PB08-03 | 8 | 51.6 | 30.8 | 10.5 | 14.5 | 11.2 | 17 |
| 9 | JS6-PB08-02 | 8 | 51.6 | 29 | 9.5 | 14.5 | 11.2 | 14 |
| 10 | JS6-PB08-01 | 8 | 51.6 | 28 | 7.5 | 14.5 | 11.2 | 12 |
| 11 | JS6-PB6-M5 | 6 | 46.8 | 26.6 | 4 | 12.5 | 9.2 | 12 |
| 12 | JS6-PB6-03 | 6 | 45.5 | 29.1 | 10.5 | 12.5 | 9.2 | 17 |
| 13 | JS6-PB6-02 | 6 | 46.8 | 28.1 | 9.5 | 12.5 | 9.2 | 14 |
| 14 | JS6-PB6-01 | 6 | 46.8 | 25.4 | 7.5 | 12.5 | 9.2 | 12 |
| 15 | JS6-PB4-M5 | 4 | 46.6 | 26.4 | 4.2 | 10.5 | 9.2 | 12 |
| 16 | JS6-PB4-02 | 4 | 46.6 | 27.6 | 9.5 | 10.5 | 9.2 | 14 |
| 17 | JS6-PB4-01 | 4 | 46.4 | 25.6 | 7.5 | 10.5 | 9.2 | 12 |
